Motor Driver
2 Phase stepping motor driver IC
| Motor Type | Full bridge 2 Phase motor driver |
|---|---|
| Function | Stepping motor control |
| Output Configuration | 2 phase stepping motor drive IC |
| Interface | PWM |
| Application | Refrigerator Damper motor, Robotics |
| Iout(A) | 400mA |
| Vin Max(V) | 17 |
| Mounting Type | SMD |
| Package | SOPW-16 |
| status | Mass |
The AP8101W is 2 phase stepping motor driver IC.
It consists of TTL compatible input circuits, dual bridge
driver outputs with flyback diodes, changing circuit
of motor coil drive voltage (Power saving circuit)
and stand-by circuit.
